DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 101
KUBOTA Z482-EB/E2B/E3B ENGINE — HEAD COVER ASSY.
HEAD COVER ASSY. (Z482-E2B/Z482-E3B)
NO. PART NO. PART NAME QTY. REMARKS
010 1G95714503 COVER CYLINDER HEAD, Z482-E2B ..............1................INCLUDES ITEMS W/#
010 1G95714504 COVER CYLINDER HEAD, Z482-E3B ..............1................INCLUDES ITEMS W/%
020# 1624173370 PIPE, WATER RETURN 1
030# 1G91105203 COMP. VALVE BREATHER 1
040# 1G80105120 COVER, BREATHER 1
050# 0302450510 SCREW WITH WASHER 4
060# 1G95805370 SHIELD, BREATHER .........................................1................Z482-E2B
070# 1G95714520 GASKET, HEAD COVER 1
080 1G91191022 BOLT 4
090 1G96005512 TUBE, BREATHER 1
100 0931888125 CLAMP, HOSE 2
120 E915133140 PLUG, OIL FILTER 1
130 0481450300 O-RING 1
To Next Page
