DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 149
KUBOTA Z482-EB/E2B/E3B ENGINE — WATER PUMP ASSY.
WATER PUMP ASSY.
NO. PART NO. PART NAME QTY. REMARKS
010 1988373030 WATER PUMP ASSY. ........................................1................INCLUDES ITEMS W/@
020@ 1585273520 FLANGE, WATER PUMP 1
030@ 1585273550 BEARING 1
040@ 1548173050 SEAL ASSY., MECHANICAL 1
050@ 1988373510 IMPELLER, WATER PUMP................................1................Z482-EB AND Z482-E2B ONLY
060@ 1585273340 PIPE, WATER RETURN 1
070 1588173432 GASKET, WATER PUMP NA .............................1................Z482-EB AND Z482-E2B
070 1687173430 GASKET, WATER PUMP NA .............................1................Z482-E3B
080 0102350622 BOLT 4
090 0102350638 BOLT 1
