DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 151
KUBOTA Z482-EB/E2B/E3B ENGINE — WATER PIPE ASSY.
WATER PIPE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
010 1584172860 PIPE, WATER 1
020 1588172870 PIPE, WATER 1
030 1584191510 STUD 1
040 0275150060 NUT, FLANGE 1
050 0931889030 CLAMP, HOSE ...................................................2................Z482-EB
050 1584172960 BAND, PIPE .......................................................2................Z482-E2B AND Z482-E3B
