DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 155
KUBOTA Z482-EB/E2B/E3B ENG. — VALVE AND ROCKER ARM ASSY.
VALVE AND ROCKER ARM ASSY.
NO. PART NO. PART NAME QTY. REMARKS
010 1460113110 VALVE, INLET 2
020 1460113120 VALVE, EXHAUST 2
030 1460113240 SPRING, VALVE 4
040 1460113330 RETAINER, SPRING 4
050 1460113360 COLLET, VALVE SPRING SET 4
060 1685113280 CAP, VALVE 4
070 1584113150 SEAL, VALVE STEM 4
080 1584114263 SHAFT, ROCKER ARM .....................................1................Z482-EB AND Z482-E2B
080 1584114264 SHAFT, ROCKER ARM .....................................1................Z482-E3B
090 1687114430 WASHER 2
100 1584194022 WASHER, FLAT 2
110 0102350610 BOLT 2
120 1584114350 BRACKET, ROCKER ARM ................................2................Z482-EB
120 1G95814350 BRACKET, ROCKER ARM ................................2................Z482-E2B AND Z482-E3B
130 1460114410 STUD .................................................................2................Z482-EB
130A 0175450640 BOLT FLANGE ...................................................2................Z482-E2B AND Z482-E3B
140 0205650060 NUT ....................................................................2................Z482-EB ONLY
150 0401250060 WASHER, FLAT .................................................2................Z482-EB ONLY
160 0451260060 WASHER, LOCK................................................2................Z482-EB ONLY
170 0541100420 PIN, SPRING 1
180 1460114310 SPRING, ROCKER ARM ...................................1................Z482-EB AND Z482-E2B
180 1460114312 SPRING, ROCKER ARM ...................................1................Z482-E3B
190 1584114030 ROCKER ARM ASSY. ........................................4................INCLUDES ITEMS W/#
200# 1584114230 SCREW, ADJUSTING 4
210# 1460114240 NUT 4
To Next Page
