DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 69
ELECTRIC PARTS ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 A5262500203 BRACKET ELECTRIC PARTS 1
2 0016906016 HEX HEAD BOLT 4
3 0601842463 RESISTOR, 30W 10 OHM 1
4 0027104012 MACHINE SCREW 2
5 0601823204 RECTIFIER, S5VB60 2
6 0027103020 MACHINE SCREW 2
7 0601823754 RELAY 1
8 0027105016 MACHINE SCREW 1
9 1569465990 LAMP TIMER .....................................................1................REPLACES 0602201273
10 0017105016 HEX HEAD BOLT 1
11 1747260604 EMERGENCY UNIT ..........................................1................REPLACES 0602200475
12 0017105025 HEX HEAD BOLT 4
13 0601815731 TERMINAL BOARD 1
14 0601815759 TERMINAL BOARD 1
15 0027105020 MACHINE SCREW 4
16 8701899004 FUSE BOX 1
16A 0601806642 FUSE, 5A 4
16B 0601806643 FUSE, 15A 2
16C 0601806644 FUSE, 30A 2
17 0027105020 MACHINE SCREW 2
18 0601827350 CONTROL UNIT 1
19 0027104010 MACHINE SCREW 2
20 1584464600 REGULATOR .....................................................1................REPLACES 1584464601
21 0017105025 HEX HEAD BOLT 2
22 16226361032 ROTARY SOLENOID .........................................1................REPLACES 1620150404
23 1992636004 ARM SOLENOID 1
24 0050403020 SPRING PIN 1
25 16226361032 HEX HEAD BOLT ...............................................1................REPLACES 0010106025
25A 0030006000 HEX NUT ...........................................................1................REPLACES 0030006000
26 0207206000 HEX NUT 2
27 D235630004 GOVERNOR ROD 1
28 031108160 WASHER, FLAT .................................................1................REPLACES 0041608000
29 0605010503 SNAP PIN 1
30 0042806000 WASHER, FLAT 1
31 505015300 SNAP PIN ..........................................................1................REPLACES 0605010502
32 0010108050 HEX HEAD BOLT 1
33A 020108060 HEX NUT ...........................................................1................REPLACES 0207008000
33 0601806640 FUSE, 65A 1
34 A5485500004 GUIDE 1
35 0016906016 HEX HEAD BOLT 2
To Next Page
