DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 83
ENCLOSURE ASSY.
ORDER CODE CHART
THE PART NUMBER ABOVE INDICATES DEFAULT
COLOR OF ORANGE. TO ORDER WITH DIFFERENT
COLOR, PLEASE ADD THE FOLLOWING LETTERS
WITH THE PART NUMBER:
MQW-WHITE
Unit serial number may be required
NO. PART NO. PART NAME QTY. REMARKS
1 A5415000202 BASE ........................................................1 ...............SEE ORDER CODE CHART BELOW
1A D2492100004 LINING 1
2 D2415100004 FLOOR PANEL .........................................1 ...............SEE ORDER CODE CHART BELOW
3 0016906016 HEX HEAD BOLT 4
4 A5415600104 DUCT ........................................................1 ...............SEE ORDER CODE CHART BELOW
5 0016906016 HEX HEAD BOLT 4
6 D2455200113 SPLASHER PANEL ..................................1 ...............SEE ORDER CODE CHART BELOW
7 D2455200003A SPLASHER PANEL ..................................1 ...............REPLACES P/N D2455200003
....................................................................................SEE ORDER CODE CHART BELOW
8 0016906016 HEX HEAD BOLT 12
9 D2425000012B FRONT FRAME, (ORANGE UNITS) ........1 ...............REPLACES P/N D2425000012
....................................................................................S/N 3757609 AND BELOW
9 D2425000022 FRONT FRAME, (WHITE UNITS) ............1 ...............S/N 3757610 AND ABOVE
9A 0220900340 RUBBER SEAL 2
10 0016906016 HEX HEAD BOLT 3
11 0016908020 HEX HEAD BOLT 2
12 D2312100004 BRACKET RADIATOR 1
13 0016906016 HEX HEAD BOLT 2
14 D2312300013 FAN SHROUD 1
14-1 D2492200004 LINING 1
14-2 0221700050 LINING 4
14-3 0221900165 LINING 4
15 0016906016 HEX HEAD BOLT 4
16 A5435300203 HANGER ...................................................1 ...............SEE ORDER CODE CHART BELOW
17 A5435300403 HANGER ...................................................1 ...............SEE ORDER CODE CHART BELOW
18 0012310025 HEX HEAD BOLT 8
19 D2485500014 HARNESS GUIDE 1
20 0016906016 HEX HEAD BOLT 2
21 A5445000102 REAR FRAME, (ORANGE UNITS) 1
21 A5445000112 REAR FRAME, (WHITE UNITS) 1
22 0016906016 HEX HEAD BOLT 4
23 D2445300004 COVER REAR FRAME .............................1 ...............SEE ORDER CODE CHART BELOW
24 0016906016 HEX HEAD BOLT 6
To Next Page
