ga6HR/ga6HRS
SPECIFICATIONS (GENERATOR)
Model GA6HR GA6HRS
Type Brushless Revolving Field Type
Excitation Solid State, Statically Excited System
Speed 3,600 RPM
Cooling System Self-Ventilation
Fuel Capacity 5 gallons (19 liters)
Continuous Power Output 5.0 kW
Max Power Output 6.0 kW
Rated Voltage 120/240V
Current Max/Continuous (120V) 50.0/41.6 amps
Current Max/Continuous (240V) 25.0/20.8 amps
Phase Single Phase (4 wire)
Frequency 60 Hz
Power Factor 1
29.9 x 30.9 X 29.7 in.
(760 X 785 X 755 mm)
29.9 x 30.9 X 29.7 in.
(760 X 785 X 755 mm)
220 lbs. (100 kg.) 238 lbs. (108 kg.)
GA6HRS Only)
Battery specifications for GA-6HRS : 12volts, 26Amp
hours, 260 amps cold cranking ability :
7-1/2" (L) X 5"(W) X 7-1I4"(H)
NOTICE
In keeping with Multiquip's policy of constantly
improving its products, the specifications quoted herein
are subject to change without prior notice.
