MTX60HD RAMMER • OPERATION AND PARTS MANUAL — REV. #3 (10/26/18) — PAGE 27
CRANKCASE AND ENGINE ASSY
NO. PART NO. PART NAME QTY. REMARKS
1 368910010 CRANKCASE CP ..............................................1 ...............INCLUDES ITEM W/
*
2
*
009120204 STUD BOLT 10X50X21T/21S 4
3 041006007 BEARING 6007Z 1
4 368347410 DRUM, PINION 1
5 060404010 OIL SEAL TC-40528 1
6 080200350 STOP RING S-35 1
7 080100620 STOP RING R-62 1
9 042506203 BEARING 6203 1
10 040006305 BEARING 6305 1
11 080100620 STOP RING R62 1
12 080200170 STOP RING S-17 1
13 JISB2804C25 SNAP RING 25MM 1
14 368347250 CONNECTING ROD 1
15 040006304 BEARING 6304 1
16 080100520 STOP RING R-52 1
17 080200200 STOP RING S-20 1
19 047940060 NEEDLE BEARING FJ-1816 1
20 050710100 0- RING AS568- 267 1
21 014208025 SOCKET HEAD BOLT 8X25 T 8
23 366348550 CLUTCH ASSY. 1
24 952401450 WASHER 8.5X22X3 1
25-1 011208025 BOLT 8X25 T 1
25-2 030208200 WASHER, LOCK M8 1
26 368217640 ENGINE FLANGE 1
28 001710840 SOCKET HEAD BOLT 8X40 T 4
29 022611010 FLANGE NUT M10 H 4
31 368347490 SHOCK ABSORBER BRACKET 60 1
32-1 012010030 BOLT 10X30 H 4
32-2 030210250 WASHER, LOCK M10 4
33 939010270 STOPPER RUBBER (70) 1
34 030208200 WASHER, LOCK M8 1
35 020108060 NUT M8 1
36 366900010 AIR CLEANER ASSY. .......................................1 ...............INCLUDES ITEMS W/ #
36-1# 366010010 AIR CLEANER COVER 1
36-2# 366010020 WASHER, FLAT M6 (6.5X18X1.5) 2
36-3# 030206150 WASHER, LOCK M6 2
36-4# 366010040 COIN BOLT M6 2
36-5# 366010050 AIR CLEANER BASE CP 1
36-7# 366010070 PRIMARY ELEMENT CP 1
36-8# 366010080 SECONDARY ELEMENT 1
36-9# 362030040 GRIP BPLT CP 1
37 366345470 INTAKE PIPE 1
38 954407681 CYCLONE CLAMP (CY- 1) 45 1
39 954407682 CYCLONE CLAMP (CY- 1) 38 1
40 366460160 UNDER SEALING FORM 1
