MTX60HD RAMMER • OPERATION AND PARTS MANUAL — REV. #3 (10/26/18) — PAGE 29
CRANKCASE AND ENGINE ASSY
NO. PART NO. PART NAME QTY. REMARKS
41 366460150 SIDE SEALING FORM 1
42-1 001220851 BOLT 8X55 T 2
42-2 030208200 WASHER, LOCK M8 2
42-3 014208020 WASHER, FLAT M8 2
43-1 011008015 BOLT 8X15 H 2
43-2 030208200 WASHER, LOCK M8 2
44 368217760 BOTTOM CLEANER COVER 60 1
45 368217750 TOP CLEANER COVER 60 1
46 366460140 RUBBER BUSH 10X16X17 2
47 366345980 CLEANER COVER KNOB 2
48 050200060 0-RING P6 2
49 009110040 FLANGE BOLT 8X20 4
50 368119470 LINK GUARD 1
51 368119480 MUFFLER GUARD 1
52 022910260 WELL NUT M8 2
53 366460170 FLANGE COLLAR 8 2
54-1 014208020 SOCKET HEAD BOLT 8X20 T 4
54-2 033910220 WASHER, FLAT M8 4
55 009110038 SOCKET HEAD BOLT 8X30 ZN 2
56 368217770 CROSS BAR 1
57 009110039 SOCKET HEAD BOLT 6X25 ZN 4
58 022910250 WELL NUT M6 4
61 368119490 ENGINE GUARD 1
62 366461050 COLLAR/GUARD 12
63 033910220 WASHER 8.4X15.5X1.6 4
64 009110038 SOCKET HEAD BOLT 8X30 ZN 4
71-1 011206020 BOLT 6X20 T 2
71-2 030206150 WASHER, LOCK M6 2
71-3 031106100 WASHER, FLAT M6 2
72 020106050 NUT M6 2
73 959006120 CLIP (TCP2-10509B) 1
74 368461280 WIRE HARNESS 1
75 2067550101 CLAMP COMPL 2
76 959021814 SPIRAL TUBE KEP6 / L=200 1
77 454010020 CLAMP TC-100 3
90 368347270 CRANK GEAR 1
101 368010010 FRONT COVER 1
121 912210014 ENGINE ASSY., GX100UKRBF 1
