ANTENNA INFORMATION
Conduit
®
Cat 4 for North America MTCDT-L4N1 Hardware Guide 15
Antenna Specifications
Category Description
Frequency Range 2.4000 to 5.150 GHz
Impedance 50 Ohms
VSWR VSWR should not exceed 2.0:1 at any point across the bands of operation
Peak Radiated Gain 4.9 dBi for 2.4GHz/ 5.5 dBi for 5 GHz on azimuth plane
Radiation Omni-directional
Polarization Linear
Connector RP-SMA(M)
LoRa Antenna
Manufacturer: PulseLarsen Antenna
Description: 868-928 MHz RP-SMA Antenna, 8"
Model Number: W1063
MultiTech ordering information:
Ordering Part Number Quantity
AN868-915A-1HRA 1
AN868-915A-10HRA 10
AN868-915A-50HRA 50
LoRa Antenna Specifications
Category Description
Frequency Range 868-928 MHz
Impedance 50 Ohms
VSWR < 2.0
Gain 1.0 dBi
Radiation Omni
Polarization Vertical
