DIP Switch and Switch Settings & Functions
(See Figure 2–3.)
Switch Function Position
1 Local Copy Enable UP*
Local Copy Suppress DOWN
2 Two-Wire Lease Line DOWN
Four-Wire Lease Line UP*
3 Two-Wire Lease Line DOWN
Four-Wire Lease Line UP*
4 Two-Wire Lease Line UP
Four-Wire Lease Line DOWN*
5 Transmit 0 dBm DOWN*
Transmit -9 dBm UP
6 Request to Send Forced On DOWN*
Request to Send Controlled by DTE UP
on Pin 4
7 Receiver Squelch Enable
DOWN*
Receiver Squelch Disable UP
NOTE: UP equals OPEN
DOWN equals CLOSED
*********************************************
ALB Analog Loopback Test Mode ALB
Normal Mode Normal*
DLB Digital Loopback Test Mode DLB
Normal Mode Normal*
* Indicates default position
