PRODUCT OVERVIEW
Power Draw MTC-H5
USB
5 volts Cellular call box Average measured TX Pulse (AVG) Total inrush charge
connection no data current (amps) at Amplitude Current measured in
(amps) maximum power (amps) MilliCoulombs (mC)
GSM850Mhz 0.044 0.263 1.17 1.65
HSDPA1800Mhz 0.041 0.477 0.532 1.65
Serial
Sleep Mode Cellular call box Average TX Pulse (AVG) Total inrush
Current (amps) connection no measured current Amplitude charge measured
data (amps)) (amps) at Current (amps) in MilliCoulombs
maximum power (mC)
7 volts
GSM850Mhz 0.014 0.033 0.184 1.113 1.85
HSDPA1800Mhz 0.014 0.033 0.322 0.372 1.85
9 volts
GSM850Mhz 0.013 0.029 0.828 0.828 1.71
HSDPA1800Mhz 0.013 0.029 0.256 0.32 1.71
32 volts
GSM850Mhz 0.005 0.013 0.057 0.325 3.54
HSDPA1800Mhz 0.005 0.013 0.094 0.144 3.54
