ANTENNA INFORMATION
MultiConnect
®
rCell 100 MTR-LTE Hardware Guide 21
Chapter 4 – Antenna Information
Antenna System Cellular Devices
The cellular/wireless performance depends on the implementation and antenna design. The integration of the
antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early
so the performance is not compromised. Devices were approved with the following antenna(s) and for alternate
antennas meeting the given specifications.
The antenna system is defined as the UFL connection point from the device to the specified cable specifications
and specified antenna specifications.
EAD Antenna Used with -LAT1 and -LVW2 Models
The cellular radio portion of the device is approved with the following antenna or for alternate antennas meeting
the given specifications.
Manufacturer: Embedded Antenna Systems, Ltd. (EAD)
Description: Dipole Blade Antenna for LTE
MultiTech ordering information:
Model Quantity
ANLTE3-2HRA 2
ANLTE3-10HRA 10
ANLTE3-50HRA 50
LTE Antenna Specifications
Category Description
Frequency Range 698-806 MHz
824-894 MHz
880-960 MHz
1710-1880 MHz
1850-1990 MHz
1920-2170 MHz
2100-2500 MHz
2500-2690 MHz
Impedance 50 Ohms
VSWR < 2.5:1
Typical Radiated Gain Low band 0.5 dBi (698-960 MHz)
High band 2.2 dBi (1710-2700 MHz)
