MTRA-FSP Installation & Operation Manual
00242600-MTRA-FSP_Manual.doc Page 7 of 16
4.2 DIP Switch Settings
The MTRA-FSP is configured using the DIP switches located on the front of the
relay enclosure.
DIP # Setting Mode Description See Section:
OFF Empty (Discharge) Mode 5.1
1
ON Fill (Charge) Mode 5.2
OFF High Level Alarm 6.1
2
ON Low Level Alarm 6.1
OFF
0.5 sec Pump Activation and Deactivation
Delay
8.2
3
ON
10 sec Pump Activation and Deactivation
Delay
8.2
OFF Constant Alarm Output 6.1
4
ON Flash Alarm Output (1Hz) 6.1
OFF 0.5 sec Alarm Activation Delay 8.2
5
ON 10 sec Alarm Activation Delay 8.2
OFF NC Alarm Output 6.1
6
ON NO Alarm Output 6.1
7 8 Probe Sensitivity 8.1
OFF OFF 1kohm
ON OFF 4kohm
OFF ON 20kohm
ON ON 80kohm
