Carefully remove and lay out all parts. Familiarize yourself with all exhibits
and diagrams to facilitate the assembly of your crib
TOOLS REQUIRED :
Allenkey (supplied)
PART ENCLOSED IN CARTON
A. Head Board ( 1 pc )
C. Side Board ( 2 pcs )
B. Foot Board ( 1 pc )
D. Stabilizer Bar ( 1 pc)
E. Mattress Spring ( 1 pc )
HARDWARE
( H ) Allenbolt 3/4"
[20 mm] (4 pcs)
( G ) Allenbolt 2" [ 50 mm ] ( 4 pcs )
( F ) Allenbolt 2 3/8" [ 60 mm ] ( 4 pcs )
( I ) Nut 3/4"
[20 mm] (8 pcs)
( J ) Allenbolt 2 3/8" [ 60 mm ] ( 4 pcs )
(K) Barrel Nut 1" [25mm]
( 4 pcs )
( P ) Spring Washer
(16 pcs)
2
Make sure the bolts are tightly locked against the washers during assembly.
(Please add an extra ½ revolution to all the bolts when using spring washer after tightening)
( L ) Allenkey ( 2 pcs ) (Length may vary)
