Munire CAPRI CURVE - Crib Assembly Steps; Assembling Crib Sides

3
STEP 1 " ASSEMBLY OF CRIB SIDES "
STEP 2.1
- Insert nut 3/4" [20 mm] ( I ) through the top and bottom holes in
headboard from the back side.
- Insert (4 pcs) allenbolt 2 3/8" [60 mm] ( F ), spring washer (P) through the top and
bottom holes in sideboard and connect to the headboard. Hand tighten only!
- Repeat STEP 2.1 for other sideboard.
STEP 2.2
- Insert barrel nut 1" [25 mm] (K) into holes in stabiliser bar
- Connect stabilizer bar to the sideboard using (4 pcs) allenbolt 2 3/8" [60 mm] (J), spring washer (P)
- Tighten all bolts with allenkey ( L )
STEP 2.2
STEP 2.2
K
D
J
I
A
L
F
STEP 2.1
FACE/AVANT
INSIDE/INTERIEUR
J
C
R
I
G
H
T
I
N
S
I
D
E
RIGHT/DROIT
INSIDE/INTERIEUR
F
P
P
P
P
A. Head Board ( 1 pc )
C. Side Board ( 2 pcs )
D. Stabilizer Bar ( 1 pc )
L. Allenkey (2 pcs)
I . Nut 3/4" [20 mm] (4 pcs)
J. Allenbolt 2 3/8" [60 mm] ( 4 pcs)
F. Allenbolt 2 3/8" [60 mm] ( 4 pcs)
K. Barrel Nut 1" [25mm] (4 pcs)
P. Spring Washer
(8 pcs)
