Munire CAPRI CURVE - Attaching Footboard

5
- Insert allenbolt 2" [50 mm] (G), spring washer (P) through the holes in sideboard
into the threaded holes footboard (B).
- Tighten with allenkey (L).
STEP 3 " ASSEMBLY OF FOOTBOARD "
THIS STEP REQUIRES :
G
G
B
P
P
G
P
B. Footboard (1 pc)
L. Allenkey (1 pc)
G. Allenbolt 2" [50 mm] ( 4 pcs)
P. Spring Washer
(4 pcs)
