4
- Attach mattress spring (E) to Side board as shown in FIG.3.
- Secure with allenkey (L).
- See FIG. 4 for height adjustment
- Make sure the mattress spring is leveled after assembly.
STEP 2 " SPRING INSTALLATION "
THIS STEP REQUIRES :
FIG. 3 .
( I )
FIG. 4 .
Lowest
position
( I )
Middle
position
Highest
position
( P )
E
E. Mattress Spring (1 pc)
L. Allenkey (2 pcs)
I . Nut 3/4" [20 mm] (4 pcs)
H. Allenbolt 3/4" [20 mm] (4 pcs)
P. Spring Washer
(4 pcs)
( H )
( H )
