4
Never use or touch the heater
with wet hands or when either the heater or
the power cable is wet.
Follow all state and local
ordinances and codes when using this
heater.
2. Product Description
This is a Diesel or Kerosene-Fueled, direct-fired air
heater. It is primarily intended for temporary
heating of buildings under construction, alteration
or repair. Direct-fired means that the combustion
products of the heater enter the heated space. This
appliance produces small amounts of carbon
monoxide. Carbon monoxide is toxic.
3. Technical Specifications
Model JAZ 42 JAZ 80 JAZ 80 W JAZ 125 JAZ 160
Heat Input [BTU/hr] 40,000 77,700 77,700 125,000 160,000
Air Flow Rating [ft³/min] 180 335 335 420 480
Fuel Type No.1 Fuel Oil (Diesel Fuel) / No.2 Fuel Oil (Diesel Fuel) / Kerosene
Fuel consumption [gal/h] 0.28 0.56 0.56 0.92 1.16
Fuel Nozzle Size 0.30 gph 0.65 gph 0.65 gph 0.85 gph 1.00 gph
Voltage 120V 60Hz
Electrical Power [W] 180 230 230 240 430
Air Pressure Setting [psi] 4.8 4.1 4.1 5.1 5.5
Current Rating [A] 1.50 2.00 2.00 2.05 3.15
Fuse rating [A] T 4A T 4A T 4A T 4A T 4A
Dimensions
Net Weight [lb] 27.3 30.4 34.6 58.9 62.2
ength [in] 26.4 26.4 32.0 36.6 36.6
Width [in] 12.5 12.5 17.7 20.5 20.5
Height [in] 16.5 16.5 24.4 25.0 25.0
Tank Capacity [gal] 5.0 5.0 5.0 11.4 11.4
Running Time [h] ~18 ~9 ~9 ~13 ~10
Standard Features
Fuel Level Indicator Sightglass Sightglass Sightglass Fuel gauge Fuel gauge
Power Cord Support yes yes yes yes yes
Handle top top rear rear + front rear + front
Ambient Thermostat built-in built-in built-in built-in built-in
Error Indicator built-in built-in built-in built-in built-in
4. Assembling Instructions
Remove the heater from its shipping carton. If
the unit is damaged in anyway, do not use it and
contact your dealer.
JAZ 42/JAZ 80: the heater is fully assembled -
no further assembly required
JAZ 80 W
The following parts are supplied with the heater
in the shipping carton.
4
