Figure4.5Ductsrequiredforinstallation
A.Processairinlet1.Dryairdamper
B.Dryairoutlet
2.Externallterbox(option)
C.Reactivationairinlet
3.Ducttransition
D.Wetairoutlet4.Reactivationairdamper
5.Outlet/inletduct(wirenetting)
190TGB-1035-H1604Installation11
