MX² 30S
MX² 35-95S
Figure 1.5 Label position
TP1
TP2
TP3
TP4
Figure 1.6 Pressure test points
TP1. Process a ir TP1–TP4. Differential pressure, process air
TP2. Wet air TP2–TP3. Differential pressure, reactivation air
TP3. Reactivation air
TP4. Dry air
