Section 30 00-02-0977
2018-02-23 - 8 -
Specifications
Interface
Display:
Monochrome HR-TFT with backlight
2.7” / 68 mm, WQVGA (400 x 240 pixels)
Languages: English, Spanish, German, French, Italian
(3) LEDs: Green (mode), Yellow (warning) and Red (shutdown)
Operator Controls:
(11) Raised silicone keypads, tactile feedback
(1) Rotary key switch, power on/off
(1) Push switch (red), engine stop
Power Supply
Operating Voltage: 8-32 VDC, reverse battery polarity and load-dump protected
Cranking Power Holdup: 0 VDC up to 50mS (also good for brownout / blackout
instances)
Current Consumption:
Power on in stopped state; 117 mA at 12 VDC.
Power on in standby mode; 52 mA at 12 VDC
Inputs (9)
(5) Digital: configurable (active on High, Low, Open)
(3) Analog: configurable (4-20 mA, 0-5V, resistive or digital ground)
(1) Frequency: supporting:
Magnetic Pickup (30 Hz – 10 kHz, 2.0 VAC – 120 VAC) and
Engine Alternator (30 Hz – 10 kHz, 4.5 VRMS – 90 VRMS)
Outputs (8)
(2) Relay: switched +DC, 10A
(1) Relay: Form C (dry / volt-free), 10A
(2) Low-side FET: (-DC), 1A
(2) High-side FET: (+DC), 1A
(1) Dedicated Alternator Excitation: +DC, 1A
Communications
(1) CAN: J1939
(1) RS485: Modbus RTU
Mating Connectors
21 Position, Deutsch HDP26-24-21SE
31 Position, Deutsch HDP26-24-31SE
Physical / Environmental
Enclosure material: Polycarbonate
Dimensions (WxHxD): 9.59 x 7.34 x 5.20 in. (243.48 x 186.5 x 132.23 mm)
Weight: 4 lbs (1.8 kg)
IP Rating: IP67
Operating and Storage Temperature: -40° to +85° C (-40° to 185° F)
Vibration: 7.86 G
rms
(5-2000 Hz), 3-axes random
Shock: ±50G, 3-axes
