Section 30 00-02-0977
2018-02-23 - 6 -
PIN Specifications
Relay 1, +DC (10A), Default Setting: Crank
Relay 2, +DC (10A), Default Setting: ECU
Enable
Alternator Excite Output, +DC (1A)
Analog Input 3, Default Setting: Not Used
Digital Output 1, +DC, (1A), Default Setting: Not in
Auto)
Digital Input 3, Default Setting: Dual Contact Stop,
B-
Digital Output 3, -DC, (1A), Default Setting:
Throttle Decrease)
Digital Output 4, -DC, (1A), Default Setting:
Throttle Increase
Relay 3 Common (RLY 3 Defaulted to Not Used)
10A Max
J1939 CAN Low (includes terminating resistor,
Default to ON)
Relay 3 NC (RLY 3 Defaulted to Not Used) 10A
Max
J1939 CAN High, (includes terminating
resistor, Default to ON)
Relay 3 NO (RLY 3 Defaulted to Not Used) 10A
Max
Analog Input 2, Default Setting: Not Used
Digital Input 5, Default Setting: Low Lube Oil Level
B-
Analog Input 1, Default Setting: Not Used
Digital Input 1, Default Setting: Not Used
NOTE: Wiring of this device must
meet all applicable electrical codes.
Digital Input 2, Default Setting: Dual Contact Start,
B-
Digital Output 2, +DC, (1A), Default Setting: Engine
Running)
Digital Input 4, Default Setting: Low Coolant Level,
B-
To Next Page
