9
OPERATING INSTRUCTIONS
Cutting Height Adjustment
NOTE: Refer to figure 11.
NOTE:
The location and appearance of the height adjustment lever may vary between
different models.
Before using the mower for the first time, raise the cutting position to the height best
suited for your lawn.
To adjust the blade height:
• To ADJUST the blade height, grasp the height adjustment lever and pull it outwards (1).
• To LOWER OR RAISE, move the lever forward / backward as shown in Fig 11 and
release. Height of the mower can be lowered by moving the lever in forward direction and
raised by moving it in backward direction (2).
WARNING
Do not adjust the height while the
mower is running.
1
2
Lever
Fig. 11
