9.2 Transmitter FSI750E
Analog output
Constant current: 4 … 20 mA
Output value: max. 20.5 mA
Load: max. 750 Ω
Load influence: ≤ 0,02 %
Damping: filter 1st order, fixed
Power supply
DC voltage: 24 VDC, -20 % to +30 %
Power consumption: max. 2 W
Power-LED/green: good-condition of power supply
Housing
Material: Polyamide
Color: light grey
Protection class: IP20
Width x length x height: 22,5 x 115 x 108 mm
(with connection terminal blocks)
Inflammability class acc. to UL 94: V0
Housing type for mounting: 35 mm DIN rails
Weight with terminal blocks: approx. 100 g
Connection terminal
Solid (minimum/maximum): 0,2 mm
2
/2,5 mm
2
Stranded wire (minimum/maximum): 0,2 mm
2
/2,5 mm
2
AWG/kcmil (minimum/maximum): 24/14
Stripping length: 7 mm
Connection method: plugable screw connection
Tightening torque: 0,5 … 0,6 Nm
