Mvac Central vacuum system - Installing Inlets; Dos and Donts (Inlet Installation)

A
B
A
B
10
Installation
11
Installation
dOs & dOn’Ts
INSTALLING INLETS
When installing your vacuum inlets, we recommend that the principle of electric
polarity be taken into account. Ensure that the wire connected onto contact A
on inlet 1 is the same as that connected to contact A on inlet 2, and so on. Do
not cross, reverse or interchange wires.
dOs & dOn’Ts
inlet 1
inlet 2
