10...30 mm
15
Subject to modications
— A gab (10 to 30 mm) should remain between the stand
and the ground.
— On the right side, pull the unlocking handle downwards.
The locking indicator is in the red zone.
— Disconnect the hydraulics and the electrics.
Loader with MACH System
— Unlock the housing of the MACH System by pressing
the safety latch on the left, then lift the handle.
— Hook the MACH System housing onto its support.
