8. IMPLEMENT UNHITCHING
This operation must be carried out by the driver, who must leave the seat and ensure
all manoeuvres are forbidden while he is working on the loader.
— Choose a level and solid surface.
— Set down the implement horizontally 0.30 m above
the ground.
— Hold the hand brake.
— Stop the tractor’s engine.
— Depressurise the hydraulic circuits to be disconnected.
NOTE: if the loader is equipped with a solenoid valve, switch
on the ignition and press the control button.
— Disconnect the hydraulics
— Mach 2: Unlock.
— Couplings: Install protective caps on the male
and female couplings.
— Put the hoses on the front of the implement.
— Unlocking the implement.
— Stand to the left of the loader, NEVER IN FRONT, pull
the locking handle towards you following (1) then (2).
— Do the same on the right hand side.
