Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 200*UD
7-16
Table 7-3 Parts Configuration Table of 200*UD models
1
Main Rotor Casing CS00100-200S 200S** 1 (S**)
1
Main Rotor Casing CS00100-200M 200M** 1 (M**)
1
Main Rotor Casing CS00100-200L 200L** 1 (L**)
2
Hexagon Socket Head Cap Screw NB35416-050 M16X50 50
3
Alignment Pin NE2016-055 φ16X55 4
4
Eye Bolt NB600-20 M20 1
5
Suction Cover CS00500-200D 200*** 1
6
Gasket, Suction Cover CS00600-200N 200*** 1
7
Eye Bolt NB600-12 M12 2
8
Spring Pin NE3206-012 φ6×12 2
9
O-ring PA12-055 JISB2401 1A G55 2
10 A Plug NF06-010 R3/8 1
10 B Plug NF06-008 R1/4 1
10 C Plug NF06-015 R1/2 1
10 D Plug NF06-015 R1/2 1
11 H Bearing Head CS01100-200DH 200*** 1 (*UD)
11 M Bearing Head CS01100-200DM 200*** 1 (*UD)
11 L Bearing Head CS01100-200DL 200*** 1 (*UD)
12 Gasket, Bearing Head CS01200-200N 200*** 1
13 Eye Bolt NB600-12 M12 1
14 Spring Pin NE3206-012 φ6x12 2
16 Bearing Cover CS01600-200D 200*** 1 (*UD)
17 Gasket, Bearing Cover CS01700-200DN 200*** 1 (*UD)
18 1 Hexagon Socket Head Cap Screw NB35416-050 M16X50 17(*UD)
18 2 Hexagon Socket Head Cap Screw NB35416-075 M16X75 8 (*UD)
19 Alignment Pin NE2010-050 φ10x50 2
20 Spring Pin NE3203-010 φ3×10 1
21 Plug NF06-010 R3/8 1
22 Balance Piston Cover CS02200-200 200*** 1
23 Gasket, Balance Piston Cover
CS02300-200N
NB35412-030
200***
M12X30
1
11
24 Hexagon Socket Head Cap Screw
25 Male Rotor
CS02520-200S
200S*
1 (S**)
26 Female Rotor
25 Male Rotor
CS02520-200M
-
200M*
200M*
1 (M**)
26 Female Rotor
25 Male Rotor
CS02520-200L
-
200L*
200L*
1 (L**)
26 Female Rotor
27 Main Bearing
CSH02700-200 Overseas
CS02700-200N Domestic
28 Side Bearing
CSH02800-200 Overseas
CS02800-200N Domestic
29 Stop Ring NG11-130 H130 4
30 Balance Piston CS03000-200 200*** 1
30 Balance Piston for high temperatures CS03000-200H 200*** DH 1
31 Key, Balance Piston CS03100-200 200*** 1
32 Stop Ring NG12-065 S65 1
33 Sleeve, Balance Piston CS03300-200 200*** 1
33
Sleeve, Balance Piston for high
temperatures
CS03300-200H 200*** DH 1
