mycom i160M

2203M4-JE-MY-iS2-N_2017.04.
Chapter 2 Compressor Specifications and Configuration
Screw Compressor i-series 2.4
Configuration of Compressor
2-29
Table 2-5 i160* Parts Configuration Table
P/N
Part name Code No. Remarks
Qty
1
Main Rotor Casing
－
i160S-* port (L, M, H)
S:1
1
Main Rotor Casing
－
i160M-* port (L, M, H)
M:1
1
Main Rotor Casing
－
i160L-* port (L, M, H)
L:1
2
Hexagon Socket Head Cap Screw
NB35416-055
M16×55 SCM435
71
3 Alignment Pin NE242A13-050A
13×50L With internal thread
and slot
4
3 Alignment Pin NE242A13-050A
13×50L With internal thread
and slot
for Motor Spacer
2
4-1
Eye Bolt
NB600-12
M12
3
4-2
Eye Bolt
NB600-24
M24
1
4-3
Eye Bolt
NB600-24
M24
1
5
Strainer Cover
CS00500-I160
i160
1
6
Gasket, Strainer Cover
CS00900-I160
i160 t=0.5
2
7-1
O-ring
PA12-150
JIS B 2401 G150
1
7-2
O-ring
PA12-140
JIS B 2401 G140
1
8
Check Valve Cover
CS00800-I160
i160
1
10-1
Hexagon Socket Head Cap Plug
NF06-004
R1/8 S45C
5
10-2
Hexagon Socket Head Cap Plug
NF06-008
R1/4 S45C
9
10-3 Hexagon Socket Head Cap Plug NF06-010 R3/8 S45C
S,L:3
M:4
10-4 Hexagon Socket Head Cap Plug NF06-015 R1/2 S45C
S, L:15
M:14
10-5
Hexagon Socket Head Cap Plug
NF06-020
R3/4 S45C
1
10-6
Hexagon Socket Head Cap Plug
NF06-025
R1 S25C
2
11
Bearing Head
CS01100-I160
i160
1
12
Gasket, Bearing Head
CS01200-I160
i160 t=0.5
1
16
Bearing Cover
CS01600-I160
i160
1
17
Gasket, Bearing Cover
CS01700-I160
i160 t=0.5
1
18-1
Hexagon Socket Head Cap Screw
NB35412-040
M12×40 SCM435
40
20
Spring Pin
NE3203-010
3×10L
1
22
End Cover
CS02200-I160N
i160
1
23
Gasket, End Cover
CS02300-I160N
i160 t=1.0
1
25 Male Rotor
－
i160SM/SF FCD S:1set
26 Female Rotor －
25
Male Rotor
－
i160MM/MF FCD M:1set
26 Female Rotor
－
25 Male Rotor －
i160LM/LF FCD L:1set
26
Female Rotor
－
27-1
Radial Bearing M
CS02800-FM160M
NU2311ET7
2
27-2
Radial Bearing F
CS02800-FM160FCT
NU2312ET7
2
29-1
Snap Ring
NG11-120
H120 C type-Internal
1
29-2
Snap Ring
NG11-130
H130 C-type-Internal
1
29-3
Snap Ring
NG12-060
S60 C type-External
1
30 Balance Piston CS03000-I160 i160 1
