mycom i160M

2203M4-JE-MY-iS2-N_2017.04.
Chapter 2 Compressor Specifications and Configuration
Screw Compressor i-series 2.4
Configuration of Compressor
2-30
P/N
Part name Code No. Remarks
Qty
30
Balance Piston (LT) CS03300-FM160LT
Special part for FM160
For H-port
1
31
Slotted Set Screw
NA14708-016
FM160 (M8×16)
1
32
Snap Ring
NG12-055
S55 C type-External
1
33
Sleeve, Balance Piston
CS03300-I160
i160
1
33 Sleeve, Balance Piston (LT)
CS03300-FM160LT
Special part for FM160
For H-port
1
34
Spring pin
NE3206-015
FM160 (6×15L)
1
35
O-ring
PA11-024
JIS B2401 P24
2
38-1
Thrust Bearing M
CS03800-FM160P
7311B Shared with FM160
1
38-2
Thrust Bearing F
CS03800-160P
7312B Shared with 160
1
39-1
Lock Nut
NG31-011
AN11
1
39-2
Lock Nut
NG31-012
AN12
1
40-1
Lock Washer
NG32-011
AW11
1
40-2
Lock Washer
NG32-012
AW12
1
41-1
Spacer, Thrust Bearing Outer Race M
CS04100-I160M
i160 M
1
41-2
Spacer, Thrust Bearing Outer Race F
CS04100-I160F
i160 F
1
42-1
Spacer, Thrust Bearing Alignment M
CS04200-I160M
i160 M
1
42-2
Spacer, Thrust Bearing Alignment F
CS04200-I160F
i160 F
1
43-1
Thrust Bearing Gland M
CS04300-I160M
i160 M
1
43-2
Thrust Bearing Gland F
CS04300-I160F
i160 F
1
45
Hexagon Socket Head Cap Screw
NB35410-050
M10×50 SCM435
8
46-1 Conical Spring Washer ND150-10
8
46-2 Plain Washer
ND193-10
JIS B 1256 Small-sized,
round-type 10-22H
8
48
Retainer, Oil Seal
CS04800-160
160***
1
49
O-ring
PA12-090
JIS B 2401 G90
1
50
Oil Seal Rareflon
CS05000-160VD
160*** (S55×70×9)
1
51
Seal cover
CS05100-160
160***
1
52
Gasket, Seal Cover
CS05200-160N
160*** t=0.5
1
58
Hexagon Socket Head Cap Screw
NB35408-030
M8×30 SCM435
8
91
Coupling Key
CS09100-160
160*** single round12×8×75
1
92
Suction Flange with hole
NX2381-125MK
ANSI #300 5"
1
92
Suction Cover Flange
CZA01-300C05B
ANSI #300 5"
1
93
Gasket, Suction Flange
PL300-125
ANSI #300 5"
1
94-1
Stud Bolt (Suction Side)
NBU703/4-103
3/4-10UNC 103L
8
94-2
Hex Nut (Suction / Discharge)
NCU1503/4-10UNC
3/4-10UNC
8
95
Discharge Flange with hole
NX2381-080MK
ANSI #300 3"
1
95
Discharge Cover Flange
CZA01-300C03B
ANSI #300 3"
1
96
Gasket, Discharge Flange
PL300-080
ANSI #300 3"
1
97
Stud Bolt (Discharge Side)
NBU603/4-10UNC
3/4-10UNC
8
100
Mechanical Seal Assembly
CS10002-160EBS
160V BBSE
1set
150-1
O-ring, Thrust Bearing Gland M
PA12-110
JIS B 2401 G110
1
150-2
O-ring, Thrust Bearing Gland F
PA12-115
JIS B 2401 G115
1
