mycom i160M

2203M4-JE-MY-iS2-N_2017.04.
Chapter 2 Compressor Specifications and Configuration
Screw Compressor i-series 2.4
Configuration of Compressor
2-31
P/N
Part name Code No. Remarks
Qty
216-1
Flange with hole , Oil Inlet Port
CR74000-025
MYCOM 25A (Male)
1
216-2
Flange Gasket, Oil Inlet Port
CR72000-025N
MYCOM 25A
1
216-3
Hexagon Head Bolt
NB35412-035
M12×35 SCM435
4
216-4 Cover Plate (for Airtight/Pressure Test) CS71500-025
MYCOM 25A
Attached at shipment.
1
235-1 Motor Spacer
CS23500-I160N for NEMA Motor Flange
1
CS23500-I160IEC50
for IEC FF500
CS23500-I160IEC60
for IEC FF600
235-2 Plate, Motor Spacer
CS23510-FM160
NEMA Motor Flange Spacer
2
FF500 Motor Flange Spacer
FF600 Motor Flange Spacer
235-3
Hexagon Socket Head Cap Screw
NB35406-010
M6×10 SCM435
8
235-4
Hexagon Socket Head Cap Screw
NB35416-055
M16×55 SCM435
12
237-1
Torsional Slip Washer M
CS23700-FM160M
FM160
1
237-2
Torsional Slip Washer F
CS23700-160
160***
1
250-1
Thrust Washer M
CS25000-FM160M
FM160
1
250-2
Thrust Washer F
CS25000-160
160*** Thrust washer
1
391
Unloader Piston
CS39100-I160
i160
2
392
Spring
CS39200-F125
FM125
2
393
Unloader Cover
CS39300-I160
i160
2
395
Gasket, Unloader Cover
CS39500-I160
i160 t=1.0
2
-
Hexagon Socket Head Cap Screw
(common to No.58)
NB35408-030 M8×30 SCM435 12
480
Strainer Element
CS48000-I160
i160 #150 Φ160×200
1
481
Retainer, Strainer Element
CS48100-I160
i160
1
485
Check Valve Spring
CS48500-I160
i160
1
486
Hexagon Nut
NC622-10
FM160(U-NUT M10)
1
487
Plain Washer
ND193-10
Small-sized SPCC1 M10
1
488
Seat Stopper
CS48800-I160
i160
1
489
Valve Seat
CS48900-I160
i160
1
490
Valve Plate
CS49000-I160
i160
1
491
Check Valve Shaft
CS49100-I160
i160
1
495
O-ring
PA11-007
JIS B 2401 P7
1
533 Solenoid Valve
KF711-XOF1
SPORLAN XOF-120V
2
KF711-XOF2
SPORLAN XOF-240V
534
Nipple (High Pressure)
NN410-100
Rc3/8×100L Sch40
2
535
Connection (L-type)
NJ3-0803NE
L-Φ8-R3/8 JO4060
2
536
Connection (L-type)
NJ3-0802KNNT
L-Φ8-R1/4 JO4050
2
538
Piping
QA1802-08
Φ8 STS
2
550 Check Union KD122-12E I-Φ12-R3/8
L: 2
S, M: 1
551 Connection (I-type) NJ2-1203NE I-Φ12-R3/8 JO4570
L: 2
S, M: 1
552
Piping
QA1802-12
Φ12 STS
1
