Chapter 2 Compressor Specifications and Configuration
Screw Compressor i-series 2.5
Mechanisms
2-37

Solenoid Valve for Capacity Control
Table 2-7 Specifications of the Solenoid Valves
Item
Solenoid Valve
SX07-03GN
(Japan domestic)
SPORLAN XOF
(Foreign)
Coil ratings Volts
AC V
100, 200
120, 208 to 240
DC V
—
24
Watts
W
11/10
10
Cycles
Hz
50/60
50/60
Piping joint
—
Rc3/8
3/8 NPT Female
Port size
mm
3
2.8
Maximum Operating
pressure differential required
Mpa 2 1.7
Note: The pressure value represents the gauge pressure.
●
Solenoid valves for capacity control are indoor specifications. Make sure not to drop
dew condensation water onto the solenoid valves by installing appropriate thermal
protection on the suction piping to the compressor.
