introduction
The Myryad MA 120, 240 and 360 Power
Amplifiers have been designed to offer
a combination of high quality sound
reproduction and simple yet elegant styling.
They can be used to provide power for high
quality stereo systems when partnered by a
suitable preamplifier such as Myryad’s MP
100, or with a Myryad integrated amplifier in
bi-amp or tri-amp systems. They can also be
used, in combination (e.g. one MA 240 Stereo
Power Amplifier plus one Myryad MA 360
Three Channel Power Amplifier), to power a
full-surround music or Home Cinema sound
system of the highest quality.
The MA 120 and MA 360 have unbalanced
line inputs plus directly linked line outputs,
all on RCA phono sockets.
The MA 240 also has unbalanced line inputs
plus directly linked line outputs, all on
RCA phono sockets but it in addition it has
balanced line inputs on professional quality
3-pin XLR sockets. Furthermore, the two
amplifier channels may be switched to
bridged-mono mode for increased power
output into a single 8Ω loudspeaker using a
rear panel switch.
All Myryad M-Series Power Amplifiers may
be controlled remotely via the My-Link
communications bus when used with other
Myryad M series products. The My-Link
allows remote control of standby and mute
functions. In addition to this, the MA 240
and MA 360 power amplifiers may be
switched into or out of standby remotely
using their DC trigger inputs.
MA 120 applications include:
• Stereo operation, delivering 2 x 60 watts
into 8Ω loudspeakers
• One MA 120 with an MI 120 Integrated
Amplifier in a bi-amplifier system
• Two MA 120s with an MP 100
Preamplifier in a bi-amplifier system
• Three MA 120s with an MP 100
Preamplifier in a tri-amplifier system
• Up to ten MA 120s and one MI 120 or
MP 100 in a multi-room system
MA 240 applications include:
• Stereo operation, delivering 2 x 120 watts
into 8Ω loudspeakers
• High power stereo operation with two
MA 240s – able to deliver 2 x 400 watts
into a minimum 8Ω load
• Stereo bi-amplifier operation with two
MA 240s, each delivering 2 x 120 watts into
8Ω loudspeakers
• Use in conjunction with the MA 360 Three
Channel Power Amplifier, delivering five
channels at 120 watts into 8Ω in Home
Cinema systems of the highest quality
MA 360 applications include:
• Use in conjunction with the MA 240 Stereo
Power Amplifier, delivering of five channels
at 120 watts into 8Ω in Home Cinema
systems of the very highest quality.
PLEASE NOTE:THIS OWNER’S MANUAL
DESCRIBES ALL THREE POWER AMPLIFIERS.
WHERE THE TEXT APPLIES TO ONLY ONE OR
TWO OF THE AMPLIFIERS THE APPLICABLE
MODEL NUMBER(S) APPEAR IN THE PARAGRAPH
HEADING. WHERE NO MODEL NUMBER IS
SPECIFIED IN THE PARAGRAPH HEADING THE
TEXT APPLIES TO ALL POWER AMPLIFIERS.
installation and
safety notes
This amplifier generates a modest amount
of heat and thus requires ventilation. Do
not place it on a rug or other soft surface
into which it could sink, obstructing the air
inlets in its underside. Do not allow papers
or cloth to obstruct the ventilation grille in
the top cover. The amplifier should not be
installed in a built-in situation such as
a bookcase or cabinet that may impede
the flow of air. If the amplifier is moved
shortly after operation take care not to touch
the heatsinks, which are accessible from
below, as they may be very hot. The amplifier
is designed for use in moderate climates.
CAUTION:TO PREVENT A FIRE OR SHOCK
HAZARD, DO NOT PERMIT THIS PRODUCT TO
BECOME WET OR EXPOSE IT TO DRIPPING OR
SPLASHING. DO NOT PLACE OBJECTS FILLED
WITH LIQUID, SUCH AS VASES, ON THE
AMPLIFIER. IF LIQUID IS ACCIDENTALLY SPILLED
ON IT, IMMEDIATELY SHUT OFF ITS POWER AT
THE WALL SOCKET AND UNPLUG THE AC
POWER CORD. ALLOW SUFFICIENT TIME FOR
COMPLETE EVAPORATION TO OCCUR BEFORE
OPERATING THE AMPLIFIER AGAIN. IF THE
LIQUID IS ANYTHING BUT WATER AND/OR
ALCOHOL, A QUALIFIED SERVICE TECHNICIAN
SHOULD EXAMINE THE AMPLIFIER BEFORE IT
IS USED AGAIN.
DO NOT PLACE NAKED FLAMES, SUCH AS
LIGHTED CANDLES ON THIS PRODUCT. DO
NOT REMOVE THE COVER, OR ATTEMPT TO
MODIFY OR REPAIR THE AMPLIFIER YOURSELF.
REFER ALL SERVICING TO A QUALIFIED
TECHNICIAN.
accessories
Your Myryad Power Amplifier is supplied
complete with the following accessories:
MA 120,MA 240 and MA 360
• Separate mains power cord to suit
country of sale.
MA 240 only
• Two “U”-shaped gold-plated XLR jumper
links. Supplied inserted into the
BALANCED input sockets. {If you remove
these links from the amplifier store them
in a safe place as they may be needed in
the future.}
contents
• Introduction 3
• Installation and safety notes 3
• Accessories 3
• Setting up your systems 4
• Rear panel connections 5
• Operating your system 7
• Front panel controls 7
• Loudspeaker output 7
protection and muting
• Trouble-shooting guide 8
• Appendix 9
• The MI 120 plus MA 120 in
“Bi-Amplified” Systems
• Using the MA 240 with an MI 120
or mixed MA 120s and MA 240s
with an MP 100 in Bi-Amp or
Tri-Amp systems
• The MI 120 plus MA 120s in
“Tri-Amplified” systems
• The MI 120 or MP 100 with one
or more 120s or MA 240s in
Multi-Room systems
• My-link 10
• Specifications 15
