24
Myson Touch RS
REMOTE SENSOR
MYSON TOUCH RS
Typical Wiring
RT
A
N
MYSON TOUCH RS
+
C
O
HEATING
L
1
A
2
-
Power Input.
230V ac
50Hz.
Switched Live
REMOTE SENSOR
RT
A
N
MYSON TOUCH RS
+
C
O
HEATING
L
1
A
2
-
Power Input.
230V ac
50Hz.
Volt Free
Wiring
Installation or repair only by qualified personnel & in accordance with IEE regulations.
A Class 'A' switch, (contact separation of at least 3mm in all poles) must be
To protect the system a fuse rated at 3 amps must be installed.
incorporated in the fixed wiring as a means of disconnecting the supply voltage.
MAINS WIRING VOLT FREE WIRING
