N-Tron 1002MC-LX-YY User Manual

(Revised 2011-09-28)
18
1005TX - KEY SPECIFICATIONS
Physical
Height: 4.0” (10.16 cm)
Width: 1.0” (2.54 cm)
Depth: 3.61” (9.165 cm)
Weight: 0.70 lbs (0.32 kg)
DIN Rail: 35 mm
Electrical
Input Voltage: 10-30 VDC (Regulated)
Input Current: 230mA max. @ 24VDC (Steady State)
Inrush Current: 13 Amp/0.61 ms max. @ 24VDC
Input Ripple: Less than 100 mV
Input Wire Size: 12-24 AWG
Environmental
Operating Temperature: -40°C to 85°C
Storage Temperature: -40°C to 85°C
Operating Humidity: 10% to 90% (Non Condensing)
Operating Altitude: 0 to 10,000 ft.
Network Media
10BaseT: > Cat-3
100BaseT: > Cat-5
1000BaseT: > Cat-5e
Connectors
10/100/1000BaseTX: Five (5) RJ45 TX Copper Ports
Recommended Minimum Wiring Clearance:
Top: 1 " (2.54 cm)
Front: 2 " (5.08 cm)
