SPECIFICATIONS - NAD 118 DIGITAL PREAMPLIFIER
Line level Inputs (CD, Video, Tuner, Tape)
Input impedance 100k + 450pF
Input sensitivity (ref. 0.5V) 80mV
Signal/Noise ratio, A-weighted 86dB
A/D Converter 106dB
Main D/A Converter 108dB
Frequency Response (20Hz-20kHz) +0.3dB
Voltage gain max. 16.5dB
THD + SMPTE + IHF I.M. 0.03%
Infrasonic filter -3dB at 24Hz
Line Level Outputs
Output Impedance Pre Out 220
Tape 100
Phones 120
Max. output level Pre out >3V
Tape >1V
Controls
Treble ±10dB at 10kHz
Bass ±10dB at 40Hz
Mid ±6.5dB at 2.8kHz
Physical specification
Dimensions in mm (Width x Height x Depth) 435 x 95 x 280
Net weight 8kg
Shipping Weight 9kg
Manufactured under licence from Trifield Productions Limited.
Patent no.s:-
UK 9211756.3
EPA 93913238.7 published as 0643899
PCT GB93/01131
