NAD 3100 User Manual

PRE-AMP SECTION
Phono input
Input impedance
(R and C) MM 47kΩ / 100pF
MC 100Ω / 1000pF
Input sensitivity, 1kHz MM 2.5mV ref. 0.5V
MC 0.18mV
Signal/Noise ratio
(A-weighted with cartridge connected) MM 75dB ref. 5mV
MC 75dB ref. 0.5mV
THD
(20Hz - 20kHz) <0.04%
RIAA response accuracy
(20Hz - 20kHz) ±0.5dB
Line level inputs
Input impedance
(R and C) 50kΩ / 500pF
Input sensitivity
(ref. 1W) 20mV
Maximum input signal 10V
Signal/Noise ratio
(A-weighted ref 1W) 94dB
Frequency response 20Hz - 20kHz / ±0.5dB
Line level outputs
Output impedance Pre-amp 600Ω
Tape Source Z + 1kΩ
Maximum output level Pre-amp 10V
Tone controls
Treble ±9dB at 10kHz
Bass ±10dB at 50Hz
Bass EQ +3dB at 55Hz
+6dB at 36Hz
Infrasonic filter
(switchable) -3dB at 12Hz - 12dB/octave
POWER AMP SECTION
Continuous output power into 8Ω * 60W (17dBW)
Rated distortion
(THD 20Hz - 20kHz) 0.03%
Clipping power
(maximum continuous power per channel) 70W
IHF Dynamic headroom at 8Ω +6dB
IHF dynamic power
(maximum short term power per channel) 8Ω 200W (23dBW)
4Ω 250W (24dBW)
2Ω 330W (25dBW)
Damping factor
(ref. 8Ω, 50Hz) >100
Input impedance 10kΩ / 600pF
Input sensitivity
(for rated power into 8Ω) 850mV
Frequency response 3Hz - 100kHz / +0, -3dB
Signal/noise ratio ref. 1W 100dB
ref. rated power 117dB
THD
(20Hz - 20kHz) <0.03%
Remote No
NAD Link No
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 435 x 106 x 385mm
Net weight 10.5kg
Shipping weight 11.6kg
Power consumption
(120 ~ 240V, 50/60Hz) 330VA
* Minimum power per chnnel, 20Hz - 20kHz, both channels driven with no more than rated distiortion.
Dimensions are of unit’s cabinet without attached feet; add up to 18mm for total height.
Dimension depth excludes terminals, sockets, controls and buttons.
© NAD Electronics. All rights reserved. E & OE

NAD 3100 Specifications

General

Power Output	50 watts per channel into 8Ω (stereo)
Input Sensitivity	150mV (line)
Speaker Load Impedance	4Ω
Input Impedance	47kΩ (line)
Frequency Response	20Hz to 20kHz
