NAD 317 - Specifications; Power Amplifier Specifications; Bridged Mode Specifications; Preamplifier Section Specifications

NA D
38
POWER AMPLIFIER
CONTINUOUS AVERAGE POWER OUTPUT INTO 8
(Min. power per channel, 20Hz-20kHz, both channels driven, with no
more than rated distortion)
Rated distortion (THD 20Hz-20kHz)
Clipping power (maximum continuous power per channel)
IHF dynamic headroom at 8
IHF dynamic power 8
(maximum short term power/channel) 4
2
Slew rate
Damping factor (ref. 8 50Hz)
Input impedance
Input impedance
Input sensitivity (for rated power into 8 )
Voltage gain
Frequency response 20Hz-20kHz
-3dB
Signal/Noise ratio, A weighted ref. 1W
ref. rated power
Bridged (Monophonic) Mode
CONTINUOUS AVERAGE POWER OUTPUT INTO 8
(Min. power, 20Hz-20kHz, with no more than rated distortion)
IHF dynamic headroom at 8
IHF dynamic power 8
4
PREAMPLIFIER SECTION
Line Level Inputs
(CD,Video,Tuner,Tape 1, Tape 2, Aux)
Input impedance (R and C)
Input sensitivity ref.0.5V
Signal/Noise ratio, A-weighted ref. 1W
Frequency response, 20Hz-20kHz
Voltage gain
THD + SMPTE + IHF I.M.
Line Level Outputs
Output impedance Pre out
Tape
Headphones
Maximum output level Pre out
Tape
Phones
Controls
Treble
Bass
Physical Specifications
Dimensions in mm (Width x Height x Depth)
Net Weight
Shipping Weight
80W (19dBW)
0.03%
105W
+1$8 dB
110W (20.4dBW)
180W (22.6dBW)
250W (24dBW)
>60V/sec
200
60k + 500pF
0.9V
x 28.3 (29dB)
±0.2dB
2Hz/100kHz
98dB
119dB
0.03%
240W (23.8dB)
+1.8dB
360W (25.6dBW)
500W (27dBW)
20 k + 450 pF
80 mV
98dB
+0.2dB
16dB
<0.02%
220
Source Z + 2k
120
>12V
>10V
>8V into 600
>250mW into 8
±7 dB at 10 kHz
±10 dB at 50 Hz
435 x 120 x 280
12kg
13.6kg
SPECIFICATION - NAD 317 STEREO INTEGRATED AMPLIFIER
