NAD C510 - Exploded View Parts List

REF.NO PART NO. DESCRIPTION Qty. REF.NO PART NO. DESCRIPTION Qty.
C001 67-388001-0 Chassis 1 R001 67-388002-0B Rear Panel 1
C002 75-124001-0 Foot 4 R002 A11-01101-03 Rocker Switch 1
C003 78-001002-1 Foot Pad 4 R003 A17-07003-01 AC Inlet 1
C004 01-35101-00 MAIN BOARD 1 R004 01-35102-00 TRIG Board 1
C005 01-35105-00 SMPS BOARD 1
F001 70-388001-0B Fascia 1 T001 67-223003-1 Top Cover 1
F002 67-388003-0 Subfascia 1
F003 76-388001-0 VFD Lens 1
F004 70-134004-0 End cap 2 S001 61-063105-0 Self Tapping Screw STF3×5 4
F005 J71-223001-0 Volume Knob 1 S002 61-023206-0 Self Ta
ping Screws BTB3×6 12
F006 Z77-223003-1 Volu
me Knob Bezel 1 S003 61-023506-0 Machine Screw M3×6 3
F007 77-223001-0 2P Input Button Bezel 1 S004 61-373506-0 Machine Screw M3×6,Ni 7
F008 J71-124002-0 2P Input Button 1 S005 61-023106-0 Self Taping Screws STB3×6 20
F009 77-124004-0 Power Button Bezel 1 S006 61-023208-0 Self Taping Screws BTB3×8 10
F010 J71-124001-0 Power Button 1 S007 61-023108-0 Self Taping Screws STB3×8 4
F011 79-124003-0 CR Foam C 1 S008 61-084108-0 Self Taping Screws STPW4X8 4
F012 79-134001-0 CR Foam 1 S009 63-010408-0 Plain Washer GB/T97.1, Ф4 1
F013 79-134002-0 Rubbe
r Pad 3 S010 63-020411-0 Spring Washer GB93-87, Ф4 1
F014 85-332002-0 Round Spacer 3.5-4.5 3 S011 62-010402-0 Nut 1
F015 01-35106-00 VFD Board 1
F016 01-35103-00 FPP Board 1
F017 01-35104-00 Encode Board 1
EXPLODED VIEW PARTS LIST
35
