NAD CI 940 - Page 19

ELECTRICAL PARTS LIST
PCB-1:MAIN BOARD
NOITPIRCSED.ON TRAP
PCB INFO
01-94001-20 Main Board
02-94001-01 Main Board
A16-94001-22 Main Board PCB
VM1.1 FR-
4,1.6mm,2Layers,1Oz,TG130,231
×260mm
DIODE
D101, D103, D104, D105, D106, D201,
D203, D204, D205, D206, D301, D303,
D304, D305, D306, D401, D403, D404,
D405, D406, D807, D809
33-44148-00 Switch Diode 1N4148
D102, D202, D302, D402, D802, D803,
D810
33-14709-00 Zener Diode 4.7V, 1/2W
14-OD W1 V42edoiD reneZ01-00421-33808D ,608D
TRANSISTOR
1045N2rotsisnarT30-10450-13206Q ,205Q
Q113, Q213, Q313 31-05551-02 Transistor 2N5551
Q102, Q103, Q104, Q202, Q203, Q204,
Q302, Q303, Q304, Q402, Q403, Q404
31-00970-00 Transistor 2SA970-GR(TPE2,F) TO-92
Q102, Q103, Q104, Q202, Q203, Q204,
Q302, Q303, Q304, Q402, Q403, Q404
or 31-01268-00 Transistor KTA1268-GR, TO-92
RG-5101ArotsisnarT40-51010-13408Q
RG-5181CrotsisnarT40-51810-13308Q ,108Q
Q105, Q205, Q305, Q405 31-02240-00 Transistor 2SC2240-GR(TPE2,F) TO-92
Q105, Q205, Q305, Q405 or 31-03200-00 Transistor
KTC3200-GR，TO-92
RESISTOR
01rotsiseR mliF lateM05-00102-70116R ,115R Ω, 1/6W, ±5%
R118, R218, R318, R418 07-21800-50 Metal Film Resistor 180Ω,1/6W,±1%
R130, R230, R330, R430 07-22709-50 Metal Film Resistor 27Ω, 1/6W, ±1%
R119, R219, R319, R419 07-20820-50 Metal Film Resistor 82Ω, 1/6W, ±5%
R108, R112, R117, R208, R212, R217,
R308, R312, R317, R408, R412, R417
07-20101-50 Metal Film Resistor 100Ω, 1/6W, ±5%
R114, R214, R314, R414 07-20331-50 Metal Film Resistor 330Ω, 1/6W, ±5%
R111, R211, R311, R411 07-20391-50 Metal Film Resistor 390Ω, 1/6W, ±5%
R101, R105, R201, R205, R301, R305,
R401, R405
07-20471-50 Metal Film Resistor 470Ω, 1/6W, ±5%
R127, R227, R327, R427 07-28660-50 Metal Film Resistor RJ13 866Ω, 1/6W, ±1%
R113, R115, R135, R136, R138, R139,
R213, R215, R235, R236, R238, R239,
R313, R315, R335, R336, R338, R339,
R413, R415, R435, R436, R438, R439
07-20102-50 Metal Film Resistor 1KΩ, 1/6W, ±5%
R126, R226, R326, R426 07-20122-50 Metal Film Resistor 1K2Ω, 1/6W, ±5%
R109, R209, R309, R409 07-22201-50 Metal Film Resistor 2K2Ω, 1/6W, ±1%
R110, R210, R310, R410 07-20222-50 Metal Film Resistor 2K2Ω, 1/6W, ±5%
2K8r
otsiseR mliF lateM05-10282-70544R ,541R Ω, 1/6W, ±5%
R124, R125, R224, R225, R503, R324,
R325, R424, R425, R603
07-20472-50 Metal Film Resistor 4K7Ω, 1/6W, ±5%
R102, R107, R202, R207, R245, R504,
R302, R307, R345, R402, R407, R604,
R801, R802, R805, R816, R817, R825
07-20103-50 Metal Film Resistor 10KΩ, 1/6W, ±5%
21
