NAD CI 940 - Page 28

C901, C908, C909, C945, C974 26-10362-12 Ceramic Chip Capacitor
10nK,630V,X7R,1206,1206CC103
KAZ1A
C970, C971 26-10422-02 Ceramic Chip Capacitor
100nK,200V,1206,X7R,C3216X7R
2E104KT
C930 26-10151-01 Ceramic Chip Capacitor
100pJ,50V,0805,NPO,C2012C0G
1H101JT
CX901, CX902, C917, C918 A25-47422-00
Interfernece Suppression
Cap
MKP62/MPX,0.47uF, 275V, 10%,
Pitch=15mm
CY901 CY902 CY903 CY904 A05-10242-00
Hign Voltage Cermatic
Capacitor
1nF,400V(X1),250V(Y1),±
20%,CT81-400VAC-08b-2E4-
102M-YA
C949 06-10051-02 Alu Electrolytic Capacitor CD263(X),10uF,50V,±20%,105℃
C946, C957 06-10042-00 Alu Electrolytic Capacitor
CD11H,10uF,400V,±20%,105
℃,F5.0
C922 06-22021-03 Alu Electrolytic Capacitor
CD263(X),22uF,25V,±
20%,F2.5,D=5mm
C962 06-10121-04 Alu Electrolytic Capacitor
CD263(X),100uF,25V,±20%,105
℃,F2.5
C963 06-10131-03 Alu Electrolytic Capacitor
CD286,100uF,35V,±20%,105
℃,F2.5
C950 06-10131-06 Alu Electrolytic Capacitor
CD263,100uF,35V,±20%,105
℃,F3.5
C929 06-47111-11 Alu Electrolytic Capacitor
CD287,470uF,10V,±
20%,Pitch=3.5mm D=8mm
C964, C965, C966, C967, C968, C969 06-56151-01 Alu Electrolytic Capacitor
CD28L 560uF,50V,±20%,105℃
C964, C965, C966, C967, C968, C969 or 06-56151-00 Alu Electrolytic Capacitor
560uF,50V,±20%,105℃
RXW561M1HBK-1325
C936, C940 06-10231-03 Alu Electrolytic Capacitor
CD287,1000uF,35V,±20%,12.5×
25,F5.0
C937, C938, C941, C955, C972 06-33121-04 Alu Electrolytic Capacitor
CD286,330uF,25V,±20%
8x11.5mm
C954 06-10221-03 Alu Electrolytic Capacitor
CD289,1000uF,25V,±20%,10×
25,F5.0
C902, C903, C977, C978 06-68122-06 Alu Electrolytic Capacitor
CD294, 680uF, 200V, ±20%, 30×
30mm
Use for C977Alu Elec
trolytic Capacitor
Caution
94-175003-0
Alu Electrolytic Capacitor
Caution Label
φ30 PET High temperature
resistance 120° Black print over
yellow
MOSFET
Q912, Q913 31-01850-03 N-ch POWER MOSFET FDP18N50
Q914, Q915, Q916, Q917 31-00412-00 MOSFET AOT412
Q931 31-00647-01 Transistor 2SB647-D
RELAY
K901 12-01101-19 Relay HF36F/012-HST(555), TV-5
INDUCTOR
L901 08-05220-00 INDUCTOR 22uH 3A, MESC-220M-01
L909, L910 J22-07422-00 Common Inductor SC7422-145A, 20mH 2A
L905, L906, L907, L908 08-02065-00 Ferriet Bead 65R/100MHZ 7A,BL01RN1A1F1J
L904 08-02339-00 Inductor 3.3uH,LGB0810-3.3uH
TRANSFORMER
T901 J22-07316-00 Transformer GATE Drive SR
T909 A22-00019-20 Transformer SBY EEL19STBHS-E
T908 A22-00042-13 Transformer ER42 CI940
TH901 A07-70022-19 Thermal Circuit Brake
ST-22 90℃ W TYPE
CONNECTOR
J903 13-23903-01 Connecter LD7.92A-2A
J902 13-23904-00 Connecter VH3.96A-4A
J904 14-94002-00 Cable UL2468#26AWG*2C , L=500mm
30
