10 +12V TRIGGER
+12V TRIGGER OUT
The +12V TRIGGER OUT is used for controlling external equipment
equipped with a +12V trigger input.
Connect this +12V TRIGGER OUT to the other equipment’s
corresponding +12V DC input jack using a mono cable with 3.5mm
male plug.
This output will be 12V when the M50.2 is ON and 0V when it is
either OFF or in standby mode.
+12V TRIGGER IN
With this input triggered by a 12V DC supply, the M50.2 can be
switched ON remotely from Standby Mode by compatible devices such
as ampliers, preampliers, receivers, etc. If the 12V DC supply is cut o,
the M50.2 will return to standby mode.
Connect this +12V Trigger input to the remote devices
corresponding +12V DC output jack using a mono cable with
3.5mm male plug. The controlling device must be equipped with a
+12V trigger output to use this feature.
11 IR IN
This input is connected to the output of an IR (infrared) repeater
(Xantech or similar) or the IR output of another component to allow
control of the M50.2 from a remote location.
To program IR Remote commands into your M50.2 via IR IN, go
to theSettings Menu,selectPlayer, IR remote.Simply select the
function desired from theIR RemoteMenu, point an IR remote
control at the IR repeater and press the button to perform that
function. Once programmed, a check-mark will appear in the
Congure IR Trigger function list.
12 AC MAINS INPUT
The M50.2 comes supplied with two separate mains power cords.
Select the mains power cord appropriate for your region.
Before connecting the plug to the mains power source, ensure that
it is rmly connected to the M50.2’s AC Mains input socket.
Always disconnect the mains power plug from the mains power
source before disconnecting the cable from the M50.2’s AC Mains
input socket.
13 POWER
The POWER switch supplies the master AC mains power for the
M50.2.
When the POWER switch is set to ON position, the M50.2 goes to
standby mode as shown by the amber status condition of the front
panel Status indicator.
If you do not intend to use the M50.2 for long periods of time (such
as when on vacation), switch o the POWER switch.
14 FUSE HOLDER
Only qualied NAD service technicians can have access to this fuse
holder. Opening this fuse holder may cause damage thus voiding
the warranty of your M50.2.
IDENTIFICATION OF CONTROLS
REAR PANEL
9
