10 +12V TRIGGER IN
With this input triggered by a 12V DC supply, the M51 can be switched
ON remotely from standby mode by compatible devices such as
ampliers, preampliers, receivers, etc. If the 12V DC supply is cut o,
the M51 will return to standby mode.
• Connect this +12V Trigger input to the remote device’s
corresponding +12V DC output jack using a mono cable with
3.5mm male plug. The controlling device must be equipped with a
+12V trigger output to use this feature.
11 IR IN
• This input is connected to the output of an IR (infrared) repeater
(Xantech or similar) or the IR output of another component to allow
control of the M51 from a remote location.
12 POWER
• Supply the AC mains power to the M51.
• When the POWER switch is set to ON position, the M51 goes to
standby mode as shown by the amber status condition of the
Standby LED. Press the front panel Standby button or remote
control’s [ON] button to switch ON the M51 from standby mode.
• If you intend not to use the M51 for long periods of time (such as
when on vacation), switch o the POWER switch.
• With POWER switched o, neither the front panel Standby button
nor remote control’s [ON] button can activate the M51.
13 AC MAINS INPUT
• The M51 comes supplied with two separate detachable mains
power cord. Select applicable mains power cord pertinent to your
region’s requirement.
• Before connecting the plug to the mains powers source, connect
rmly rst the other end to M51’s AC Mains input socket.
• Always disconnect the mains power plug from the mains power
source rst, before disconnecting the other end from the M51’s AC
Mains input socket.
IDENTIFICATION OF CONTROLS
REAR PANEL
8
