NAD S250 - Exploded View Parts List

EXPLODED VIEW PARTS LIST
Location Part Number Description Quantity
1 S100-2011-3 POWER BUTTON 1
2 S250-2002-1 FRONT PANEL 1
3 S250-2003-3 SUBFASCIA 1
4 S250-2014-3 LEFT SIDE PANEL 1
5 S250-2024-3 RIGHT SIDE PANEL 1
6*AH S250-2006-2 REAR PANEL 120V 1
6*C S250-2006-2 REAR PANEL 230V 1
7 S250-2057-1 REAR PANEL BAR B 1
8 S250-2047-1 REAR PANEL BAR A 1
9 S250-2027-4 HEATSINK B 1
10 S250-2017-4 HEATSINK A 4
11 S250-2037-2 HEATSINK BAR 1
12 S250-2005-2 TOP COVER 1
13 S250-2034-1 BASE PLATE 1
14 S100-2013-2 DIECAST FOOT 4
15 5600.0005 TIE-WRAP 4
16 1806-3520-0 STANDBY TRANSFORMER 1
17 4554.0052 POWER TRANSFORMER 1
18*C 1806-3519-0 EMI FILTER 20DBAG5 1
19 5200-3441-0 POWER SWITCH 1
20 2113-1206-0 RCA JACK 5
21 4208.001 SPEAKER TERMINAL BLACK 5
22 4208.0009 SPEAKER TERMINAL RED 5
23 2113-1144-0 AC INLET 1
24 4152-4621-0 LEVEL KNOB 5
25 PCB-N0920C-SW 12V TRIGGER PCB 1
26*AH PCB-N0920C-AMP POWER AMP PCB 120V 1
26*C PCB-N0921C-AMP POWER AMP PCB 230V 1
27*AH PCB-N0920C-PSU PSU PCB 120V 1
27*C PCB-N0921C-PSU PSU PCB 230V 1
28 PCB-N0920C-PSW POWER LED PCB 1
29 PCB-N0920C-LED PROTECT LED PCB 1
30 5180.0004 TRANSFORMER BOLT/NUT 1
Parts marked with the symbol are critical with regard to the risk of fire and electric shock.
Replace only with parts recommended by the manufacturer.
