1. LEVEL CONTROL 5. 12V TRIGGER INPUT
2. INPUT JACK 6. SPEAKER TERMINALS
3. SOFT CLIPPING SWITCH 7. AC INLET
4. AUTO TRIGGER SWITCH
Five Channel Power Amplifier S250
3
4
1 2
NA
D
SOFT CLIPPING
PROTECTION
1. POWER SWITCH 3. PROTECTION INDICATOR
2. POWER INDICATOR 4. SOFT CLIPPING INDICATOR
FRONT PANEL / REAR PANEL VIEW
FRONT PANEL CONTROLS
The graphic symbol of a lightning flash with an arrow point
within a triangle signifies that there is dangerous voltage
within the unit and it posses a hazard to anyone removing
the cover to gain access to the interior of the unit. Only
qualified service personnel should make such attempt.
The graphic symbol of an exclamation point within
an equilateral triangle warns a user of the device
that it is necessary to refer to the instruction
manual and its warnings for proper operation of
the unit.
REAR PANEL CONNECTIONS
AC MAINS INPUT
120V
TRIGGER IN
+12V
AUTO TRIGGER
2
1
3
4 5
6
7
1
