Nagra – HD DAC
Operating your HD DAC
Nagra Modulometer
The Modulometer, or “modulation meter” was inherited
from the second professional recorder developed by
Nagra back in 1952, the Nagra II. The Modulometer is a
typical Nagra precision instrument that displays the
necessary information to make the best possible
recordings.
In the case of the HD DAC, the Modulometer displays
the digital input level. The 0 dB corresponds to full
scale signal, meaning the maximum digital level.
The modulomenter, in the HD DAC is a twin pointer digitally controlled
instrument.
Left channel - black pointer
Right channel - red pointer
Modulometer and display intensity adjustment
This two-way toggle switch allows you to adjust the display and
Modulometer backlight intensity. Pushing the toggle UP will increase
the intensity, pushing it down will lower the intensity all the way to
complete extinction. There are 7 different intensity levels.
