Nagra – HD DAC
Technical specifications
Below are the typical specifications for the Nagra HD DAC.
Your own specific HD DAC’s exact specifications are to be found on the “protocol”
delivered with your unit.
Inputs
2 x S/P DIF, 2 AES/EBU, 1 Optical, 1 Audio USB
(mode 2), 1 x I
2
S (Nagra format)
Internal processing:
5,6 MHz / 6,2 MHz
72 bits
Compatible digital
formats
PCM 24 bits up to 384 kHz, DXD, DSD x 2.
Analog outputs
1 stereo RCA
1 stereo XLR
Symmetrical on optional
transformers
Output level
1.3 or 2 V rms
Analog output Noise
level:
-128 dBr @ 1 kHz 1.3V
linear
Distortion
< 0.02%
@ -20dBFS
THD + N
< 0.03 %
@ 192 kHz
Frequency Response
5 Hz - 40 kHz
+0 / -1 dB
Crosstalk
99 dB
Inter-channel phase
<0.1°
@ 20 kHz
Dimensions
280 x 350 x 76mm
12 x 13,7 x 3 inches
Weight
5 Kg / 11 lbs
Without power supplies
