NAIM FLATCAP 2 - Power Supply Rear Panels

4
power
Power Supply Rear Panels
mains input
ch1
nc
-ve
ch 2
Sockets 3, 4, 5
+ve
ch1
ch2
-ve
+ve
Socket 1
ch1
nc
-ve
ch 2
Sockets 1, 2, 3
+ve
ch1
ch2
-ve
+ve
Socket 4
1
2
3 4 5
1 2 3 4
1 2 3 4 5 6
6
7
Socket 2
+ve
nc
nc
-ve
+ve
ch1
nc
ch 2
-ve
Sockets
2, 3, 4, 6
Sockets 1, 5
+ve
ch1
-ve
+ve
ch2
Socket 6
NAC 252 only
Socket 7
NAC 252 or
SNAXO only
Note
The Flatcap 2 features various technologies to reduce
microphonic effects, in particular a compliant mounting for the
main circuit boards and the DIN sockets on the rear. Some
movement of the board and sockets when
connecting/disconnecting is normal.
mains input
Supercap
Hi-cap
Flatcap 2
mains input
mains input
output flying
lead
NAPSC
