NAIM FLATCAP 2 - NAC 252 Connection to Supercap

5
cable
direction
marker
4 to 4 pin DIN
240° 5 to 5 pin DIN
Burndy
Interconnect Cables
NAC 252 connection to Supercap
Note
Extra Supercap, Hi-cap or Flatcap 2 for SNAXO or IXO5.
Supercap - socket 5, Hi-cap - socket 3, Flatcap 2 - socket 2.
to SNAXO or IXO5
mains input
Hi-cap
Note
For best performance the
Burndy and 5 pin DIN
cables should be run as
close together as
possible.
mains input
to stereo power amplifiers
or to IXO5 using internal power supply
to mono or dual mono
power amplifiers
additional signal output
Supercap
NAC 252
